Press Skid
The press tending system caters to small to medium-sized parts. The depicted robot is a Fanuc M-10iD/12, operated by an R-30iB Mate Plus controller. This versatile system is compatible with various Fanuc robot models and can integrate seamlessly with press brakes of different brands and ages.
7th Axis Press cell
The press brake tending cell is enhanced with a 6m RTU (Remote Terminal Unit) to augment its capabilities. This system facilitates the processing of medium to large-sized parts efficiently. Additionally, there are options available to incorporate tool changing functionalities for both the press brake and the robot's end-of-arm tool. Within this system, there are designated infeed and outfeed platforms, each equipped with removable pins to accommodate various pallet sizes or multiple small pallets, thus extending operational duration.
Furthermore, a 60x80 squaring table is provided for the placement of parts from the infeed pallet. To streamline programming, an adjustable reposition stand is available for use after or during the bending sequence. Once programmed, operators can seamlessly oversee and manage the cell through the integrated Human Machine Interface (HMI).
